Featured Products
QX-218
Technique Specification
| System type: | 2 unit reverse phase | ||||||||
| Rated power: | 1400W | ||||||||
| Maximum power: | 2800W | ||||||||
| Peak power: | 5600W | ||||||||
| Nominal impedance: | 4 OHMS | ||||||||
| Recommended rated output power of amplifier: | 1200W -1500W @8 OHMS | ||||||||
| Nominal sensitivity ( 1W@1m ): | 104dB | ||||||||
| Maximum sound pressure level: | 135dB@1400w(138dB@2800W) | ||||||||
| Frequency bandwidth: | 35Hz—300Hz | ||||||||
| Nominal directivity ( -6dB ): | ---------- | ||||||||
| Transducer configuration: | low frequency driver 18″ 460mm unit with 100mm voice coil × 220Magnetic Steel *2 | ||||||||
| Frequency division Mode : | Passive | ||||||||
| Connector: | SPEAKON NL SPEAKON NL4 ×1 PIN1 +/2+POS PIN1-/2-NEG | ||||||||
| Box material: | 18mm ( 0.7″ ) MDF Medium density fiber board | ||||||||
| Color: | Dark gray,can be customized other color | ||||||||
| Box size: | W 600mm* D 700mm *H 1044mm | ||||||||
| NET Weight : | 95kg | ||||||||
| Reference application domain | suitable for multi function hall ,auditorium , lecture hall ,conference room,KTV,bar,Etc | ||||||||
QX-118
Technique Specification
| System type: | 1 unit reverse phase | |||||||
| Rated power: | 700W | |||||||
| Maximum power: | 1400W | |||||||
| Peak power: | 2800W | |||||||
| Nominal impedance: | 8 OHMS | |||||||
| Recommended rated output power of amplifier: | 1000W @8 OHMS | |||||||
| Nominal sensitivity ( 1W@1m ): | 102dB | |||||||
| Maximum sound pressure level: | 130dB@700w(133dB@1400W) | |||||||
| Frequency bandwidth: | 35Hz—300Hz | |||||||
| Nominal directivity ( -6dB ): | ---------- | |||||||
| Transducer configuration: | low frequency driver 18″ 460mm unit with 100mm voice coil × 220Magnetic Steel *1 | |||||||
| Frequency division Mode : | Passive | |||||||
| Connector: | SPEAKON NL SPEAKON NL4 ×1 PIN1 +/2+POS PIN1-/2-NEG | |||||||
| Box material: | 18mm ( 0.7″ ) MDF Medium density fiber board | |||||||
| Color: | Dark gray,can be customized other color | |||||||
| Box size: | W 600mm* D 700mm *H 531mm | |||||||
| NET Weight : | 48kg | |||||||
| Reference application domain: | suitable for multi function hall ,auditorium , lecture hall ,conference room,KTV,bar,Etc | |||||||
CS-06
Technique Specification
| System type: | 2 unit 2 phase inversion | ||||||||
| Rated power: | 100W | ||||||||
| Maximum power: | 200W | ||||||||
| Peak power: | 400W | ||||||||
| Nominal impedance: | 8 OHMS | ||||||||
| Recommended rated output power of amplifier: | 150W -200W @8 OHMS | ||||||||
| Nominal sensitivity ( 1W@1m ): | 96dB | ||||||||
| Maximum sound pressure level: | (119dB@200W) | ||||||||
| Frequency bandwidth: | 85Hz—20KHz | ||||||||
| Nominal directivity ( -6dB ): | 80*H*80*V | ||||||||
| Transducer configuration: | the low frequency driver 6.5″ ( 160mm unit 38mm voice coil 130mm Magnetic Steel )*1 | ||||||||
| the high frequency driver 3″ ( 25mm voice coil 90mm Magnetic Steel )*1 | |||||||||
| Frequency division Mode : | Passive From | ||||||||
| Connector: | SPEAKON NL SPEAKON NL4 ×1 PIN1 +/2+POS PIN1-/2-NEG | ||||||||
| SPEAKON PIN1+/1-2 Place Termina | |||||||||
| Box material: | 15mm ( 0.6″ ) MDF Medium density fiber board | ||||||||
| Color: | |||||||||
| Box size: | W 230mm* D 175mm *H 315mm | ||||||||
| NET Weight : | 5kg | ||||||||
| Reference application domain: | suitable for meeting room and fixed installation can be used as assistant | ||||||||
DB-25NW/DB25OW
Technique Specification
| System type: | 3 unit 3 phase inversion | |||||||
| Rated power: | 1000W | |||||||
| Maximum power: | 2000W | |||||||
| Peak power: | 4000W | |||||||
| Nominal impedance: | 4 OHMS | |||||||
| Recommended rated output power of amplifier: | 1000W -2000W @4 OHMS | |||||||
| Nominal sensitivity ( 1W@1m ): | 103dB | |||||||
| Maximum sound pressure level: | 133dB@1000W(136dB@2000W) | |||||||
| Frequency bandwidth: | 40Hz—16.5KHz | |||||||
| Nominal directivity ( -6dB ): | 100*H*70*V | |||||||
| Transducer configuration: | the low frequency driver 15″ (380mm unit 75mm voice coil 220mm Magnetic Steel )*1 | |||||||
| the high frequency driver 30″ ( 75mm voice coil 170mm Magnetic Steel )*1 | ||||||||
| Frequency division Mode : | Passive | |||||||
| Connector: | SPEAKON NL4 ×1 PIN1 +/2+POS PIN1-/2-NEG | |||||||
| Box material: | 18mm ( 0.7″ ) High density fiber board | |||||||
| Color: | the Default is black, caan be customized according to the requirements of other colors | |||||||
| Box size: | W 500mm* D500mm *H 1161mm /W500mm*H 1161mm | |||||||
| NET Weight : | 55kg | |||||||
| Reference application domain: | suitable flow performance , multi-funcation hall, | |||||||
DB15M-3G
Technique Specification
- System Type: 2-unit 2-way bass reflex
- Rated Power: 500W
- Maximum Power: 1000W
- Nominal Impedance: 8 OHMS
- Recommend Amplifier Rated Output Power: 600W—1000W@8 OHMS
- Sensitivity(1W@1m): 97dB
- SPL: 124dB@500W (127dB@1000W)
- Coverage(-6dB): 50°×100°Hor. ×50°Ver
- Frequency Bandwidth: 45Hz—18KHz
- Transducer Configuration:
- Low frequency driver 15″ (75mm voice coil 180mm magnet) x1
- High frequency driver 3″ (75mm voice coil 165mm magnet) x1
- Connector: SPEAKON NL4×2 PIN1+/2+POS. PIN1-/2-NEG.
- Cabinet Material: 15mm (0.6″) plywood
- Color: The default is black, other colors can be customized.
- Product Dimension (W×D×H): 573mm×372mm×715mm
- Packaging Dimension (W×D×H): 560mm×535mm×790mm
- Weight: 28.6Kg
- Reference Application Field: Suitable for multi-function hall, auditorium, lecture hall, conference room, KTV, bar and other fixed installation
DB25-3G
Technique Specification
- System Type: 5-unit 3-way bass reflex
- Rated Power: 1000W
- Maximum Power: 2000W
- Nominal Impedance: 4 OHMS
- Recommend Amplifier Rated Output Power: 1500W—2000W@4 OHMS
- Sensitivity (1W@1m): 100dB
- SPL: 130dB@1000W (133dB@2000W)
- Coverage (-6dB): 100°Hor.×60°Ver
- Frequency Bandwidth: 45Hz—18KHz
- Transducer Configuration:
- Low frequency driver 15″ (75mm voice coil 180mm magnet) ×2
- NdFeB medium frequency driver 6.5″ (45mm voice coil 85mm magnet) ×2
- High frequency driver 3″ (75mm voice coil 165mm magnet)×1
- Connector: SPEAKON NL4×2 PIN1+/2+POS. PIN1-/2-NEG.
- Cabinet Material: 18mm (0.7″) plywood
- Color: The default is black, other colors can be customized.
- Product Dimension (W×D×H): 593mm×525mm×1286mm
- Packaging Dimension (W×D×H): 660mm×595mm×1365mm
- Weight: 71.3Kg
- Reference Application Field: Suitable for multi-function hall, auditorium, lecture hall, conference room, KTV, bar and other fixed installation
DB218-3G
Technique Specification
- System Type: 2-unit bass reflex
- Rated Power: 1400W
- Maximum Power: 2800W
- Nominal Impedance: 4 OHMS
- Recommend Amplifier Rated Output Power: 2000W—300W@4 OHMS
- Sensitivity (1W@1m): 102dB
- SPL: 133dB@1400W (136dB@2800W)
- Coverage (-6dB): 360°Hor. ×360°Ver
- Frequency Bandwidth: 37Hz—300Hz
- Transducer Configuration: Low frequency driver 18″ (100mm voice coil 220mm magnet) ×2
- Connector: SPEAKON NL4×2 PIN1+/2+POS. PIN1-/2-NEG.
- Cabinet Material: 18mm (0.7″) plywood
- Color: The default is black, other colors can be customized.
- Product Dimension (W×D×H): 980mm×690mm×598mm
- Packaging Dimension (W×D×H): 1055mm×765mm×670mm
- Weight: 69.8Kg
- Reference Application Field: Suitable for multi-function hall, auditorium, lecture hall, conference room, KTV, bar and other fixed installation
MTL700-3G
Technique Specification
- System Type: 2-unit 2-way bass reflex
- Rated Power: 500W
- Maximum Power: 1000W
- Nominal Impedance: 8 OHMS
- Recommend Amplifier Rated Output Power: 600W—1000W@8 OHMS
- Sensitivity (1W@1m): 97dB
- SPL: 124dB@500W (127dB@1000W)
- Coverage(-6dB): 50°×100°Hor. ×50°Ver
- Frequency Bandwidth: 46Hz—18KHz
- Transducer Configuration:
- Low frequency driver 15″ (75mm voice coil 200mm magnet) ×1
- NdFeB high frequency driver 2.5″ (65mm voice coil 110mm magnet) ×1
- Connector: SPEAKON NL4×2 PIN1+/2+POS. PIN1-/2-NEG.
- Cabinet Material: 18mm (0.7″) plywood
- Color: The default is black, other colors can be customized.
- Product Dimension (W×D×H): 530mm×420mm×728mm
- Packaging Dimension (W×D×H): 605mm×490mm×805mm
- Weight: 32.5Kg
- Reference Application Field: Suitable for multi-function hall, auditorium, lecture hall, conference room, KTV, bar and other fixed installation
NEW ARRIVALS
AT-06
TECHNICAL SPECIFICATION
System type: 2-unit 2-way phase inversion
Rated power:100W
Maximum power: 200W Peak power: 400W
Nominal sensitivity (1w@1m): 96db
Nominal Impedance: 8 OHMS
Recommended amplifier rated output power : 200W—300W@8 OHMS
Maximum sound Pressure level: 116dB@100W (119dB@200W)
Frequency Bandwidth:80Hz—20KHz
Transducer Configuration: Low frequency driver 5″ (165mm unit 35 voice coil) ×1 NdFeB high frequency driver 1″ (25mm voice coil ) ×1 Frequency division
Mode: Passive
Connector : Speakon NL4x2pin 1+/2+POS PIN1-/2-NEG
Box seize: 190mm×210mm×310mm
Weight: 5.0Kg
AT-12
TECHNICAL SPECIFICATION
System Type: 2-unit 2-unit bass reflex
Rated Power: 450W
Maximum Power: 900W Peak Power: 1800W
Nominal Impedance: 8 OHMS
Recommend Amplifier Rated Output Power: 500W-650W@8 OHMS
Nominal Sensitivity(1W@1m): 97dB Max. SPL: 124dB@450w (126dB@900w)
Coverage: 90°H×70°V
Frequency Bandwidth: 58Hz-20KHz Crossover
Mode: Passive
Transducer Configuration: Low frequency driver 12" (305mm unit 75mm voice coil ) ×1 High frequency driver 1.7" (44mm voice coil ) ×1
Connector: SPEAKON NL4×2 PIN1+/2+POS. PIN1-/2-NEG.
Cabinet Material: 18 mm(0.7") high quality plywood
Color: The default is black, other colors can be customized.
Product Dimension: W375 mm*D340 mmH656mm
Weight: 22 kg
CS-06
Technique Specification
| System type: | 2 unit 2 phase inversion | ||||||||
| Rated power: | 100W | ||||||||
| Maximum power: | 200W | ||||||||
| Peak power: | 400W | ||||||||
| Nominal impedance: | 8 OHMS | ||||||||
| Recommended rated output power of amplifier: | 150W -200W @8 OHMS | ||||||||
| Nominal sensitivity ( 1W@1m ): | 96dB | ||||||||
| Maximum sound pressure level: | (119dB@200W) | ||||||||
| Frequency bandwidth: | 85Hz—20KHz | ||||||||
| Nominal directivity ( -6dB ): | 80*H*80*V | ||||||||
| Transducer configuration: | the low frequency driver 6.5″ ( 160mm unit 38mm voice coil 130mm Magnetic Steel )*1 | ||||||||
| the high frequency driver 3″ ( 25mm voice coil 90mm Magnetic Steel )*1 | |||||||||
| Frequency division Mode : | Passive From | ||||||||
| Connector: | SPEAKON NL SPEAKON NL4 ×1 PIN1 +/2+POS PIN1-/2-NEG | ||||||||
| SPEAKON PIN1+/1-2 Place Termina | |||||||||
| Box material: | 15mm ( 0.6″ ) MDF Medium density fiber board | ||||||||
| Color: | |||||||||
| Box size: | W 230mm* D 175mm *H 315mm | ||||||||
| NET Weight : | 5kg | ||||||||
| Reference application domain: | suitable for meeting room and fixed installation can be used as assistant | ||||||||
CS-08
| MODEL | CS-08 |
| TECHNICAL SPECIFICATION | |
| System type | 2 unit 2 phase inversion |
| Rated power | 150 W |
| Maximum power | 300 W |
| Peak Power | 600 W |
| Nominal sensitivity (1w@1m) | 97 dB |
| Nominal Impedance | 8 OHMS |
| Recommended amplifier rated output power | 200W -350W @8 OHMS |
| Directivity (-6dB) | 80 H x 80 V |
| SPL | 135dB@700w(138dB@1400w) |
| Frequency Bandwidth | 70Hz—20KHz |
| Transducer Configuration | the low frequency driver 8″ ( 210mm unit 38mm voice coil 130mm Magnetic Steel )*1 the high frequency driver 3″ ( 25mm voice coil 90mm Magnetic Steel )*1 |
| Frequency division mode | Passive |
| Connector | Speakon NL4x2pin 1+/2+POS PIN1-/2-NEG |
| Box Material | 15mm ( 0.6″ ) MDF Medium density fiber board W 278mm* D 210mm *H 370mm |
| Weight | 8KG |
FEATURED PRODUCTS
Our customer service specialists are available
We will be happy to help you anytime
Free consultation with the team
Leave your mobile phone number and we will call you back
Top Rated Product
AT-06
TECHNICAL SPECIFICATION
System type: 2-unit 2-way phase inversion
Rated power:100W
Maximum power: 200W Peak power: 400W
Nominal sensitivity (1w@1m): 96db
Nominal Impedance: 8 OHMS
Recommended amplifier rated output power : 200W—300W@8 OHMS
Maximum sound Pressure level: 116dB@100W (119dB@200W)
Frequency Bandwidth:80Hz—20KHz
Transducer Configuration: Low frequency driver 5″ (165mm unit 35 voice coil) ×1 NdFeB high frequency driver 1″ (25mm voice coil ) ×1 Frequency division
Mode: Passive
Connector : Speakon NL4x2pin 1+/2+POS PIN1-/2-NEG
Box seize: 190mm×210mm×310mm
Weight: 5.0Kg
AT-12
TECHNICAL SPECIFICATION
System Type: 2-unit 2-unit bass reflex
Rated Power: 450W
Maximum Power: 900W Peak Power: 1800W
Nominal Impedance: 8 OHMS
Recommend Amplifier Rated Output Power: 500W-650W@8 OHMS
Nominal Sensitivity(1W@1m): 97dB Max. SPL: 124dB@450w (126dB@900w)
Coverage: 90°H×70°V
Frequency Bandwidth: 58Hz-20KHz Crossover
Mode: Passive
Transducer Configuration: Low frequency driver 12" (305mm unit 75mm voice coil ) ×1 High frequency driver 1.7" (44mm voice coil ) ×1
Connector: SPEAKON NL4×2 PIN1+/2+POS. PIN1-/2-NEG.
Cabinet Material: 18 mm(0.7") high quality plywood
Color: The default is black, other colors can be customized.
Product Dimension: W375 mm*D340 mmH656mm
Weight: 22 kg
CS-06
Technique Specification
| System type: | 2 unit 2 phase inversion | ||||||||
| Rated power: | 100W | ||||||||
| Maximum power: | 200W | ||||||||
| Peak power: | 400W | ||||||||
| Nominal impedance: | 8 OHMS | ||||||||
| Recommended rated output power of amplifier: | 150W -200W @8 OHMS | ||||||||
| Nominal sensitivity ( 1W@1m ): | 96dB | ||||||||
| Maximum sound pressure level: | (119dB@200W) | ||||||||
| Frequency bandwidth: | 85Hz—20KHz | ||||||||
| Nominal directivity ( -6dB ): | 80*H*80*V | ||||||||
| Transducer configuration: | the low frequency driver 6.5″ ( 160mm unit 38mm voice coil 130mm Magnetic Steel )*1 | ||||||||
| the high frequency driver 3″ ( 25mm voice coil 90mm Magnetic Steel )*1 | |||||||||
| Frequency division Mode : | Passive From | ||||||||
| Connector: | SPEAKON NL SPEAKON NL4 ×1 PIN1 +/2+POS PIN1-/2-NEG | ||||||||
| SPEAKON PIN1+/1-2 Place Termina | |||||||||
| Box material: | 15mm ( 0.6″ ) MDF Medium density fiber board | ||||||||
| Color: | |||||||||
| Box size: | W 230mm* D 175mm *H 315mm | ||||||||
| NET Weight : | 5kg | ||||||||
| Reference application domain: | suitable for meeting room and fixed installation can be used as assistant | ||||||||
Our Products
BEST SELLERS
News
Motivity provides several products in the audio field Our products are certified worldwide, registered as a trademark in the USA and China
16
Jun
Product Promotion | MotiVity MT-305 professional conference microphone
Parturient in potenti id rutrum duis torquent parturient sceler isque sit vestibulum a posuere scelerisque viverra urna. Egestas tristi...
16
Jun
22
Jun
Product Promotion | MotiVity MICROPHONE
Motive dynamic microphone black color
Mauris torquent mi eget et amet phasellus eget ad ullamcorper mi a ...
